Bearing 32926 Tapered Roller Bearing 130x180x32mm

Product Specification:

Model 32926
Size 130x180x32mm
Brand LLH or as your request
Original China or as your request

See Price

Product Details
Description
Specification
Our factory

Bearing 32926 Tapered Roller Bearing 130x180x32mm

inch ball bearing

A tapered roller bearing is a unit that consists of both tapered raceways (inner and outer rings), and tapered rollers. The construction is intended for combination loads, such as dual acting axial and radial loads.

The inner and outer ring raceways are segments of cones and the rollers are tapered so that the conical surfaces of the raceways, and the roller axes, if projected, would all meet at a common point on the main axis of the bearing. This geometry makes the motion of the cones remain coaxial, with no sliding motion between the raceways and the OD of the rollers.

bearing 32926 best groove ball bearing

1,Q: Are you trading company or manufacturer ?
A: We are factory.
2,Q: How long is your delivery time for bearing 32926?
A: Generally it is 3-5 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
3,Q: Do you provide samples for bearing 32926? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
4,Q: What is your terms of payment for bearing?
A: Payment<=1000USD,100% in advance.Payment>=1000USD, 30% T/T in advance,pay the balance before shippment.
5, Q:Could you accept OEM and customize for bearing 32926?
A:YES,we can customize for you according to sample or drawing.
6, Q: When can I get the price?
A: after we get your inquiry,usually within 2-6 hours.Urgent will be faster.
7,Q:How about your quality of bearing 32926?
A:Our quality of bearings is based on ISO9001 and quality of bearing is our soul.
8, Q: What is the MOQ for bearing 32926?
A: Usually ≥1, According your demand.
9,Q: Will you check these products before shipment?
A: Yes, before shipment products will be strictly inspection on our factory QC Process System.We have a professional QC team.
10, Q: What will we do if If you are not satisfied with the bearing 32926?
A: If have any abnormal, Please contact us at first time, we will immediately processing.

If you need any brand bearings or any models of bearings, please contact me!

Contact: Grace
Email: ntn@llhbearing.com
Skype:+8618668903871
MP/Whatsapp: +8618668903871
Wechat:GraceXu1234

Baring model	32932 J2/Q	Size-mm	16022038
Weight-kg	4.19	Brand	(othes brand we also have)
Basic dynamic load rating (C)	349kN	Reference speed	2200r/min
Basic static load rating (C0)	540kN	Limiting speed	2600r/min

high speed bearing

dimensions			Designation
d	D	T
mm
85	150	38.5	32217 J2/Q
85	150	49	33217/Q
85	180	63.5	32317 J2
85	180	44.5	31317 J2
85	150	30.5	30217 J2/Q
85	180	63.5	32317 BJ2
88.9	152.4	39.688	593/592 A/Q
90	140	39	33018/Q
90	150	45	33118/Q
90	190	67.5	32318 J2
90	150	45	33118 TN9/Q
90	160	32.5	30218 J2
90	145	35	JM 718149 A/110/Q
90	140	32	32018 X/Q
90	160	42.5	32218 J2/Q
90	190	46.5	31318 J2
90	147	40	HM 218248/W/2A/210/2A/Q
90	190	46.5	30318 J2
92.075	152.4	39.688	598/592 A/Q
95	200	49.5	30319
95	200	71.5	E2.32319
95	145	32	32019 X/Q
95	170	45.5	32219 J2
95	180	49	T7FC 095/CL7CVQ051
95	200	71.5	32319 J2
95	200	49.5	31319 J2
95	170	34.5	30219 J2
95	145	39	33019/Q
95.25	152.4	39.688	594/592 A/Q
95.25	168.275	41.275	683/672/Q
95.25	152.4	39.688	594 A/592 A/Q
95.25	171.45	47.625	77375/77675/Q
95.25	168.275	41.275	683/672
95.25	146.05	33.338	47896/47820/Q
100	215	56.5	31320 XJ2/CL7CVQ051
100	215	51.5	30320 J2
100	150	39	33020/Q
100	150	32	32020 X/Q
100	160	41	JHM 720249/210/Q
100	180	37	30220 J2
100	157	42	HM 220149/110/Q
100	140	25	32920/Q
100	215	77.5	32320 J2
100	145	24	T4CB 100/Q
100	165	47	T2EE 100
100	180	63	33220
101.6	168.275	41.275	687/672
105	225	81.5	32321 J2
105	160	35	32021 X/Q
105	160	43	33021/Q
105	190	53	32221 J2
105	190	39	30221 J2
107.95	158.75	23.02	37425/2/37625/2/Q
110	170	47	33022
110	240	84.5	32322
110	240	63	31322 XJ2
110	200	41	30222 J2
110	170	38	E2.32022 X
110	170	38	32022 X/Q
110	150	25	32922/Q
110	240	54.5	30322 J2
110	200	56	32222 J2
110	180	56	33122
114.3	180.975	34.925	68450/68712
114.3	177.8	41.275	64450/64700
120	180	48	33024
120	260	68	31324 XJ2
120	215	43.5	30224 J2
120	165	29	32924
120	260	90.5	E2.32324
120	170	27	T4CB 120
120	180	38	32024 X
120	260	59.5	30324 J2
120	260	90.5	32324 J2
127	196.85	46.038	67388/67322
127	182.562	39.688	48290/48220/Q
130	230	67.75	32226 J2
130	230	43.75	30226 J2
130	180	32	32926
130	230	67.75	E2.32226
130	280	72	31326 XJ2
130	280	63.75	30326 J2
130	200	45	32026 X
133.35	196.85	46.038	67391/67322
133.35	177.008	25.4	L 327249/210
139.7	228.6	57.15	898/4/892/HA4Q
139.7	236.538	42	HM 231132/110
140	195	29	T4CB 140
140	190	32	32928
140	250	45.75	30228 J2
140	300	77	31328 XJ2
140	250	71.75	32228 J2
149.225	236.538	57.15	HM 231148/110
150	210	32	T4DB 150
150	225	59	33030
150	320	82	31330 XJ2
150	270	49	30230
150	270	77	32230 J2
150	225	48	32030 X
152.4	222.25	46.83	M 231649/610/VQ051

high quality bearing

Jinan Maolei bearing Co.,Ltd. is located in the “Spring City” Jinan. We insist on the philosophies of “integrity” and “pragmatic & win-win business”. We also adhere to the “people-oriented” and “advancing” enterprise spirit . “Quality first and customers utmost” is honored as our enterprise concept.The core products of Jinan Maolei bearing Co,.Ltd. We have our own brand “LLH”,we sincerely welcome friends from all over the world come to visit our company and talk on business,we adhere to the concept of”survival of high quality”,and provide excellent service for customers. precision bearing
