sealed angular contact bearings 3200-2RS angular spherical plain bearings factory

sealed angular contact bearings have raceways in the inner and outer rings that are displaced with respect to each other in the direction of the bearing axis


Product Specification:

  • Model 3200-2RS
  • Size 10*30*14.3mm
  • Brand LLH or as your request
See Price

sealed angular contact bearings 3200-2RS angular spherical plain bearings factory

sealed angular contact ball bearings

sealed angular contact bearings have raceways in the inner and outer rings that are displaced with respect to each other in the direction of the bearing axis. This means that they are designed to accommodate combined loads, i.e. simultaneously acting radial and axial loads.ealed angular contact bearings

sealed angular contact bearings main application:

(1)single row angular contact ball bearing used in:

Machine shaft,high frequence motor,gas turbine, centrifugal separator, small cars front wheel , differential pinions axis

(2)double row angular contact ball bearing used in:

oil pump, ROM. Watts blower , Air compressor , All kinds of transmission , Fuel injection pump , Printing machinerysealed angular contact bearings

FAQ:

1,Q: Are you trading company or manufacturer ?

A: We are factory.

2,Q: How long is your delivery time for sealed angular contact bearings 3200 angular spherical plain bearings?

A: Generally it is 3-5 days if the goods are in stock.or it is 15-20 days if the goods are not in stock, it is according to quantity.

3,Q: Do you provide samples for sealed angular contact bearings 3200 angular spherical plain bearings ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

4,Q: What is your terms of payment for sealed angular contact bearings 3200 angular spherical plain bearings ?

A: Payment<=1000USD, 100% in advance.Payment>=1000USD, 30% T/T in advance ,pay the balance before shippment.

5, Q:Could you accept OEM and customize?

A:YES,we can customize for you according to sample or drawing.

6, Q: When can I get the price?
A:  after we get your inquiry, usually within 2-6 hours.Urgent will be faster.

7,Q:How about your quality of sealed angular contact bearings 3200 angular spherical plain bearings?

A:Our quality of bearings is based on ISO9001 and quality of bearing is our soul.

8, Q: What is the MOQ of your sealed angular contact bearings 3200 angular spherical plain bearings?
A: Usually ≥1, According your demand.

9,Q: Will you check these products before shipment?

A: Yes, before shipment products will be strictly inspection on our factory QC Process System.We have a professional QC team.

10, Q: What will we do if  you are not satisfied with the sealed angular contact bearings 3200 angular spherical plain bearings?
A: If have any abnormal, Please contact us at first time, we will immediately processing.

If you need any brand bearings or any models of bearings, please contact me!

Contact: Grace
Email: ntn@llhbearing.com
Skype:+8618668903871
MP/Whatsapp: +8618668903871
Wechat:GraceXu1234

Name High Precision Ball Bearing
Brand LLH
Model NO. 3200
Inner Size: 10mm
Outer Siez: 30mm
Package: Original Single box package + Big Paper Box + Pallet
Material chrome steel

high speed bearing

Bearing No . Bore O.D. Width  Chamfer r/min  Load Rating Dynamic Cr Ball Complement  Limiting speed Weight
d Open Seal No. Size Grease  Oil  Kg
mm mm mm mm Cr Cor Cr Cor mm r/min  r/min
3200 5200 10 30 14.3 0.6 7.35 5.35 7 4.55 18 3.969 16000 20000 0.055
3201 5201 12 32 15.9 0.6 9.7 7.15 9 6.3 18 4.763  14000 18000 0.063
3202 5202 15 35 15.9 0.6 9.7 7.45 9 6.95 20 4.763 12000 16000 0.072
3203 5203 17 40 17.5 0.6 13.2 8.15 12.7 8.35 18 5.556 11000 14000 0.091
3204 5204 20 47 20.6 1 19.7 12.6 16 10.8 18 7.144 8800 12000 0.12
3205 5205 25 52 20.6 1 21.4 14.8 18.9 13.8 20 7.144 7700 10000 0.19
3206 5206 30 62 23.8 1 29.7 21.3 25.4 18.3 18 8.731 6400 8600 0.29
3207 5207 35 72 27 1.1 41 29 31.7 24.6 18 10.731 5500 7300 0.43
3208 5208 40 80 30.2 1.1 44.4 33.6 36.5 29.1 20 11.113 5000 67000 0.57
3209 5209 45 85 30.2 1.1 49.9 38.4 41.7 33.9 20 11.509 4600 6100 0.62
3210 5210 50 90 30.2 1.1 53.3 43.6 44.1 37.9 22 11.509 4300 5100 0.67
3211 5211 55 100 33.3 1.1 65.9 55.2 52.9 44.7 22 12.7 4000 5300 1.03
3212 5212 60 110 36.5 1.1 74.4 60.8 62.6 55.9 22 13.49 3500 4700 1.4
3300 5300 10 35 19 0.6 2.11 2.62 1.314 2.375 14600 20000 0.092
3301 5301 12 37 19 0.6 1.76 3.1 1.507 2.674 13500 18000 0.109
3302 5302 15 42 19 1 15.2 11.9 13.9 10.87 18 5.556 11000 14000 0.13
3303 5303 17 47 22.2 1 21.7 17.1 20.43 16.82 9400 13000 0.2
3304 5304 20 52 22.2 1.1 24.7 15 19.8 12.8 18 8300 11000 0.23
3305 5305 25 60 25.2 1.1 32.7 20.8 27.5 18.5 16 9.525 9600 9200 0.35
3306 5306 30 72 30.2 1.1 41 28.8 34.3 25.2 16 11.906 5800 7700 0.51
3307 5307 35 80 34.9 1.5 51.2 36.2 46.1 32.8 16 13.494 5100 6800 0.79
3308 5308 40 90 36.5 1.5 62.7 45.4 51.4 37.8 16 15.081  4600 6100 1.05
3309 5309 45 100 39.7 1.5 75.1 55.7 68.9 51.5 16 16.669 4100 5500 1.42
3310 5310 50 110 44.4 1.5 84.9 62.6 16 18.256 4000 5300 1.96

high quality bearing

Jinan Maolei bearing Co.,Ltd. is located in the “Spring City” Jinan. We insist on the philosophies of “integrity” and “pragmatic & win-win business”. We also adhere to the “people-oriented” and “advancing” enterprise spirit . “Quality first and customers utmost” is honored as our enterprise concept.The core products of Jinan Maolei bearing Co,.Ltd. We have our own brand “LLH”,we sincerely welcome friends from all over the world come to visit our company and talk on business,we adhere to the concept of”survival of high quality”,and provide excellent service for customers.precision bearing
