Home > Product > Deep Groove Ball Bearing > 6307 Deep Groove Ball Bearing 35x80x21mm Single Row Chrome Steel Bearing 6307 Price

< >

6307 Deep Groove Ball Bearing 35x80x21mm Single Row Chrome Steel Bearing 6307 Price

Product Specification:

Model 6307
Size 35x80x21mm
Original China

See Price

Product Details
Description
Specification
Our factory

6307 Deep Groove Ball Bearing 35x80x21mm Single Row Chrome Steel Bearing 6307 Price

Our bearing 6307 is a standard single row deep groove ball bearing with size 35×80×21mm. We offer competitive bearing 6307 price with reliable original quality and bulk order discount.

6307 is a widely used single-row deep groove ball bearing with standard dimensions of 35mm bore × 80mm outer diameter × 21mm width. Made of high-quality chrome bearing steel, it features high hardness, wear resistance and long service life.

Adopting deep raceway groove design, the 6307 bearing can efficiently bear radial load and bidirectional light axial load. It runs with low friction, low noise and stable high-speed performance, with grease lubrication limiting speed up to 8500 rpm.

Available in open type, 6307ZZ metal shielded and 6307 2RS rubber sealed versions. Sealed types effectively prevent dust and moisture, retain internal grease and reduce maintenance needs. C3 clearance option is suitable for high temperature and high-speed working conditions to avoid thermal expansion jamming.

With simple structure and easy installation, 6307 bearing is widely applied in electric motors, fans, water pumps, compressors, general machinery and transmission equipment. Stable quality and competitive price make it a cost-effective choice for bulk purchase.

1,Q: Are you trading company or manufacturer ?
A: We are factory.
2,Q: How long is bearing 6307 price delivery time ?
A: Generally it is 3-5 days if the goods are in stock.or it is 15-20 days if the goods are not in stock, it is according to quantity.
3,Q: Do you provide bearing 6307 price samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
4,Q: What is your terms of payment for bearing?
A: Payment<=1000USD,100% in advance.Payment>=1000USD, 30% T/T in advance,pay the balance before shippment.
5, Q:Could you accept OEM and customize ?
A:YES,we can customize for you according to sample or drawing.
6, Q: When can I get the bearing 6307 price ?
A: after we get your inquiry, usually within 2-6 hours.Urgent will be faster.
7,Q:How about your quality?
A:Our quality of bearings is based on ISO9001 and quality of bearing is our soul.
8, Q: What is the MOQ?
A: Usually ≥1,According your demand.
9,Q: Will you check these products before shipment?
A: Yes, before shipment products will be strictly inspection on our factory QC Process System.We have a professional QC team.
10, Q: What will we do if If you are not satisfied with the product?
A: If have any question,Please contact us at first time, we will immediately processing.

If you need to get the latest bearing 6307 price and detailed specification, please contact us for quotation,pls contact:

Contact: Grace
Email: ntn@llhbearing.com
Skype:+8618668903871
MP/Whatsapp: +8618668903871
Wechat:GraceXu1234

d	35 mm	Bore diameter
tΔdmp	-0.01 – 0 mm	Deviation limits of mid-range bore diameter
D	80 mm	Outside diameter
tΔDmp	-0.011 – 0 mm	Deviation limits of mid-range outside diameter
B	21 mm	Width
tΔBs	-0.06 – 0 mm	Deviation limits of ring width
d1	≈49.56 mm	Shoulder diameter
D2	≈69.2 mm	Recess diameter
r1,2	min.1.5 mm	Chamfer dimension
	P6 and tighter width tolerance	ISO tolerance class for dimensions

high speed bearing

New model	China old model	specification(mm)	weight(kg)
New model	China old model	dxDxB	weight(kg)
6300	300	10x35x11	0.053
6301	301	12x37x12	0.06
6302	302	15x42x13	0.082
6303	303	17x47x14	0.115
6304	304	20x52x15	0.142
6305	305	25x62x17	0.232
6306	306	30x72x19	0.346
6307	307	35x80x21	0.457
6308	308	40x90x23	0.639

high quality bearing

Jinan Maolei bearing Co.,Ltd. is located in the “Spring City” Jinan. We insist on the philosophies of “integrity” and “pragmatic & win-win business”. We also adhere to the “people-oriented” and “advancing” enterprise spirit . “Quality first and customers utmost” is honored as our enterprise concept.The core products of Jinan Maolei bearing Co,.Ltd. We have our own brand “LLH”,we sincerely welcome friends from all over the world come to visit our company and talk on business,we adhere to the concept of”survival of high quality”,and provide excellent service for customers.

precision bearing
