Thrust ball bearing size chart greaseless ball bearings

Thrust ball bearing size chart greaseless ball bearings are separable, i.e. the shaft washer, housing washer(s), ball and cage assembly(s) can be mounted separately. Shaft washers have a ground bore to enable an interference fit. The bore of the housing washer is turned and always larger than the shaft washer bore.


Product Specification:

  • Model 51305
  • Brand LLH
  • Origin China
See Price

Thrust ball bearing size chart greaseless ball bearings

china thrust ball bearing size chart

greaseless ball bearings

Thrust ball bearing size chart greaseless ball bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them.Assembly and mounting is a simple operation as the parts are separate.They support axial loads in one direction.Clearance is provided in the bore of one of the raceways to allow for alignment.

51305 thrust ball bearing size chart

thrust ball bearing size chart 51305

greaseless ball bearings

FAQ:
1,Q: Are you trading company or manufacturer ?
A: We are factory.
2,Q: How long is your delivery time for Thrust ball bearing size chart greaseless ball bearings?
A: Generally it is 3-5 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
3,Q: Do you provide samples for Thrust ball bearing size chart greaseless ball bearings? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
4,Q: What is your terms of payment for bearing?
A: Payment<=1000USD,100% in advance.Payment>=1000USD, 30% T/T in advance,pay the balance before shippment.
5, Q:Could you accept OEM and customize for Thrust ball bearing size chart greaseless ball bearings?
A:YES,we can customize for you according to sample or drawing.
6, Q: When can I get the price?
A: after we get your inquiry, usually within 2-6 hours.Urgent will be faster.
7,Q:How about your quality of Thrust ball bearing size chart greaseless ball bearings?
A:Our quality of bearings is based on ISO9001 and quality of bearing is our soul.
8, Q: What is the MOQ for Thrust ball bearing size chart greaseless ball bearings?
A: Usually ≥1, According your demand.
9,Q: Will you check these products before shipment?
A: Yes, before shipment products will be strictly inspection on our factory QC Process System.We have a professional QC team.
10, Q: What will we do if If you are not satisfied with bearing?
A: If have any abnormal, Please contact us at first time, we will immediately processing.
If you need any Thrust ball bearing size chart greaseless ball bearings or any models of bearings, please contact me!

Contact: Leon
Email: nsk@zyslbearing.com
Skype: lh19881023
MP/Whatsapp: +8615098916271
Wechat:leon15098916271

Material chrome steel or stainless steel material
Brand LLH or OEM
Standard DIN GB ISO JIS BA ANSI
Grade ABEC-3 ABEC-5 , ABEC-7, ABEC-9
Clearance C0, C3 ,C5
Package carton package
Used Machine



precision greaseless ball bearings

Model

DIA (mm) Weight (kg)
d d1 D H
52202 15 10 32 26 0.085
52204 20 15 40 26 0.144
52205 25 20 47 28 0.23
52206 30 25 52 29 0.26
52207 35 30 62 34 0.405
52208 40 30 68 36 0.54
52209 45 35 73 37 0.64
52210 50 40 78 39 0.71
52211 55 45 90 45 1.12
52212 60 50 95 46 1.15
52213 65 55 100 47 1.36
52214 70 55 105 47 1.52
52215 75 60 110 47 1.6
52216 80 64 115 48 1.73
52217 85 70 125 55 2.22
52218 90 75 135 62 3.14
52220 100 85 150 67 4.2

high quality greaseless ball bearings

Jinan Maolei bearing Co.,Ltd. is located in the “Spring City” Jinan. We insist on the philosophies of “integrity” and “pragmatic & win-win business”. We also adhere to the “people-oriented” and “advancing” enterprise spirit . “Quality first and customers utmost” is honored as our enterprise concept.The core products of Jinan Maolei bearing Co,.Ltd. We have our own brand “LLH”,we sincerely welcome friends from all over the world come to visit our company and talk on business,we adhere to the concept of”survival of high quality”,and provide excellent service for customers.

precision greaseless ball bearings
