Miniature cam follower bearings installation

135 Published by admin May 10,2023

Miniature cam follower bearings installation:
1.After the centre line of the mounting hole is at a right Angle to the movement direction of the miniature cam follower bearings, the side of the mounting hole should be correctly positioned according to the size shown in the ladypress to fix the ladypress.
Please do not hit the flange of the miniature cam follower bearings directly with hammer during installation, otherwise miniature cam follower bearings will cause poor rotation or fracture.miniature cam follower bearings
2. The mark on the side of the rod end flange indicates the oil hole position of the track surface. When installing, it is necessary to pay attention not to install the oil hole in the load domain.The oil hole located in the load domain will shorten the service life of the bearing. The vertical hole in the center of the rod end is used for refueling or stopping.
3. The maximum tightening torque range shown in the size table should not be exceeded when tightening the nut. Excessive tightening torque will sometimes cause the screw end to break. In addition, use lock nuts, spring washers or special lock nuts if used under working conditions that may loosen the nuts.miniature cam follower bearings
4. The bit S of the outer ring of the miniature cam follower bearings with eccentric shaft sleeve can be adjusted by rotating the screwdriver wrench or hexagonal hole at the top of the rod end. The rod end can be fixed with a spring washer and other screws tightened. The maximum tightening torque range shown in the dimension table should not be exceeded when tightening the nut.
