Do you know installation method for grade 25 ball bearings?

202 Published by admin Apr 10,2019

Grade 25 ball bearings installation method:
Grade 25 ball bearings installation method 1: force fit: grade 25 ball bearings inner ring and shaft tight fit, outer ring and bearing hole is a loose fit, press the bearing to be pressed on the shaft are available, and then put the shaft together with the bearing load bearing hole, when pressed on the grade 25 ball bearings inner ring end face, cushion the assembling casing made of a soft metal material (copper or mild steel), bearing outer ring and bearing hole tight fit, inner ring and the shaft is a loose fit, the bearing can be pressed into the bearing hole first, then assembling casing diameter should be slightly less than the diameter of a hole.

precision grade 25 ball bearings
Grade 25 ball bearings installation method 2:Heating cooperates: the grade 25 ball bearings or bearing by heating, the use of thermal expansion will fit into a loose fit method of installation. Installation method is a kind of common and energy saving. This method is suitable for interference quantity larger the installation of the grade 25 ball bearings, the bearing before hot charging type or separable bearing ring into the fuel tank even heat 80-100 ℃, and then loaded on the shaft, as soon as possible out of the oil to prevent inner ring after cooling end face and the shoulder joint is not tight, to axial bearing cooling can then tighten.

grade 25 ball bearings

Bearing outer ring and light metal bearing seat tight fit, by heating the hot charging method of the bearing, can avoid the mating surface scratch.Heating tank with bearing and should be at a certain distance from the bottom of a mesh, or hanging hooks in the bearings, bearing on the bottom, in case of heavy impurities into the bearing or uneven heating, fuel tank must have a thermometer, strictly control the oil temperature shall not exceed 100 ℃.
If you need grade 25 ball bearings or need any other bearings, please also contact me!
Contact: Leon
Email: nsk@zyslbearing.com
Skype: lh19881023
MP/Whatsapp: +8615098916271
